SHOP PRODUCTSScot Pump Gasket Replacement
| Part No | Description | List Price |
|---|---|---|
| 116.000.126 | GASKET FIBER AVF FLANGE | $22.00 |
| 116.000.156 | GASKET 5.0 SQ X 3.75 X .12 VERT FLG NEO FOR WVF16 | $22.00 |
| 116.000.157 | GASKET NOBESTOS | $6.31 |
| 116.000.215 | GASKET BUNA | $9.08 |
| 116.000.217 | GASKET NOBESTOS .87 ID X 1.25 OD X .015 THK | $2.41 |
| 116.000.230 | GASKET BRG VELLUMOID 5.18ID X 6.62OD X.015 THK PMP 89 SUP2.5 | $6.31 |
| 116.000.232 | GASKET BRG VELLUMOID 3.68ID X 5.18OD X.015 THK PMP 89 SUP2.5 | $6.31 |
| 116.000.249 | GASKET BUNA 1.70 ID X 2.40 OD .125 THK FOR 108-197 | $17.34 |
| 116.000.259B | GASKET GRAPHOIL 3.88 OD 3.75 WATER JACKET .031 THK | $34.00 |
| 116.000.260A | GASKET CASE GRAPHFOIL PUMP 11 & 60 | $67.00 |
| 116.000.261 | GASKET 104\105 NOBESTOS 8.25 ID | $39.00 |
| 116.000.264 | GASKET NOBESTOS 2.94 ID X 3.31 OD X.031 THK FOR PMP95/97/102 | $15.39 |
| 116.000.267 | GASKET 95/96 NOBESTOS 10.25 ID | $40.00 |
| 116.000.272A | GASKET BACKPLATE GRAPHFOIL PMP 11, 16 & 60 | $56.00 |
| 116.000.273 | GASKET 57 NOBESTOS 7.00 ID | $21.00 |
| 116.000.276 | GASKET 103 NOBESTOS 8.12 ID | $36.00 |
| 116.000.293 | GASKET 97 NOBESTOS | $57.00 |
| 116.000.330 | GASKET GRAPHFOIL .032 PMP 11 | $36.00 |
| 137.000.506 | GASKET NON-ASBESTOS ELBOW,TANK FLANGE 69C | $15.39 |
| 137.001.103 | GASKET SILICON 60 NSF TITLE 21 CFR. CH. 1 PARA. 177.2600 | $48.00 |
| 137.001.138 | GASKET SILICON 60 NSF TITLE 21 CFR. CH. 1 PARA. 177.2600 | $19.02 |
| 137.001.139 | GASKET SILICON 60 NSF TITLE 21 CFR. CH. 1 PARA. 177.2600 | $27.00 |
| 137.001.241 | GASKET RETAINING NUT NYLON 13/16" I.D. | $234.00 |
| 137.001.242 | GASKET SLEEVE NYLON 7/8" I.D. | $146.00 |
| 137.001.243 | GASKET SLEEVE NYLON 1" I.D. | $146.00 |
| 137.001.690 | GASKET 268 NOBESTOS | $67.00 |
| 137.001.783 | GASKET 98 NOBESTOS | $67.00 |
Scot Pump Gasket
Replacement gaskets for sale online
Pump Solutions #1 Corporation carries all the OEM Scot Pump replacement parts you need, including the Scot Pump replacement gaskets for end suction centrifugal pumps.
We have a large selection of Scot Pump gaskets in nobestos, buna-N (nitrile rubber), fiber, graphoil, and silicon as well as nylon gasket sleeves. If you need help identifying the right replacement gasket for your Scot Pump we are more than happy to help.
REQUEST AN EXPERT CONTACT US TODAY
About centrifugal pump gaskets
All types of centrifugal pumps require high-quality gaskets for proper sealing. It’s important to use the right gasket material for your pump based on its design and application, especially if specific chemical or thermal resistance is required. A gasket is a type of static seal, which means there is no movement at the juncture being sealed. O-rings are another type of static seal.
Centrifugal pump impellers are designed to reduce leakage with features like balance holes and vanes on the back of the impeller, but these methods will not completely eliminate the pressure of fluid wanting to escape the pump casing. Mechanical seals are also necessary to prevent leakage.
We sell several different types of centrifugal pump gaskets for Scot Pump products as well as repair kits including seals. For help finding the right replacement parts for your pump, just give us a call or contact us online.
Contact us online for more information or help ordering replacement gaskets.
